Polyester -Rundschlinge
Shengyu ist ein professioneller Hersteller von Hebemaschinen, der sich über viele Jahre auf den Exporthandel konzentriert. Die von DOHO® hergestellte Polyester -Rundschlinge ist ein weit verbreitetes Hebewerkzeug, das eine Vielzahl von Hebeproblemen lösen kann.
Anfrage absenden
Produktbeschreibung
Polyester round sling is a widely used lifting tool, the main material of polyester round sling is polyester fiber, which is a high-strength, wear-resistant synthetic fiber, with excellent physical and chemical properties.
Product characteristics:
1. Strong,flexible,lightweight,high resistance to abrasion,shock absorbing
2. Standard:EN1492-1:2008(Europe Standard)
3. Material:100% Polyester
4. Length:1m-80m make as client’s require
5. Load capacity:1T-300T
6. Safety factor:7:1,6:1, 5:1
Product parameter
| Colour | Working load limit with 1 webbing sling | Working load limit with 2 webbing sling | |||||||||
Straight lift (T) | Choked lift (T) | 0°-7° | 7°-45° | 45°-60° | Up to 45° | 45°-60° | Straight up to 45° | Choker up to45° | Straight 45°-60° | Choker 45°-60° | |
| purple | 1 | 0.8 | 2 | 1.4 | 1 | 0.7 | 0.5 | 1.4 | 1.12 | 1 | 1 |
| green | 2 | 1.6 | 4 | 2.8 | 2 | 1.4 | 1 | 2.8 | 2.24 | 2 | 1.6 |
| yellow | 3 | 2.4 | 6 | 4.2 | 3 | 2 | 1.5 | 4.2 | 3.36 | 3 | 2.4 |
| gray | 4 | 3.2 | 8 | 5.6 | 4 | 2.8 | 2 | 5.6 | 4.48 | 4 | 3.2 |
| red | 5 | 4 | 10 | 7 | 5 | 3.5 | 2.5 | 7 | 5.6 | 5 | 4 |
| brown | 6 | 4.8 | 12 | 8.4 | 6 | 4.2 | 3 | 8.4 | 6.73 | 6 | 4.8 |
| blue | 8 | 5.4 | 16 | 11.2 | 8 | 5.6 | 4 | 11.2 | 8.96 | 8 | 6.4 |
| orange | 10 | 8 | 20 | 14 | 10 | 7 | 5 | 14 | 11.2 | 10 | 8 |
| 12 | 9.6 | 24 | 16.8 | 12 | 8.4 | 6 | 16.8 | 19.44 | 12 | 9.6 | |
| 15 | 12 | 30 | 21 | 15 | 10.5 | 7.5 | 21 | 16.8 | 15 | 12 | |
| 20 | 16 | 40 | 28 | 20 | 14 | 10 | 28 | 22.4 | 20 | 16 | |
| 25 | 20 | 50 | 35 | 25 | 17.8 | 12.5 | 35 | 28 | 25 | 20 | |
| 30 | 24 | 60 | 42 | 30 | 21 | 15 | 42 | 33.6 | 30 | 24 | |
| 50 | 40 | 100 | 70 | 50 | 35 | 25 | 56 | 56 | 50 | 40 | |
| 60 | 48 | 120 | 84 | 60 | 42 | 30 | 67.2 | 67.2 | 60 | 48 | |
Features:
1.Light and soft, easy to handle and store.
Non-conductive, non-corrosive, no reverse harm to the human body.
2.It has the characteristics of shock absorption, corrosion resistance, non-flammable, non-explosive and so on.
3.It has a protective effect on the surface of the object to be lifted, especially suitable for precision instruments and objects with strict external surface requirements.
Applications:
Polyester round sling is widely used in various lifting operations, such as machinery manufacturing, shipbuilding, petrochemical, electric power construction and other fields. It can be used with lifting equipment such as hooks, and is suitable for lifting objects under a variety of lifting conditions.
Precautions for use:
When using polyester round sling, ensure that they are hung directly into the center of the hook force to avoid crossing, twisting or knotting.
The lifting process should be directed by personnel with relevant qualifications, and overload is strictly prohibited.
When the load has sharp corners, edge goods, must use sheath, corner protection and other methods to protect the sling.
After using the lifting belt, the hanging storage method should be selected to maintain its good performance and extend its service life.
